Single Row Angular Contact Ball Bearing

Name: Single Row Angular Contact Ball Bearing
Brand: SCREW TECHNOLOGY CO.,LTD.
Price: 300 USD
Rating: 4.4 (5 reviews)

VXO Bearings' single-row angular contact ball bearings are designed to excel in precision and performance.

Our single-row angular contact bearings are engineered to handle axial loads in just one direction, making them ideal for applications requiring precise load handling and alignment. Typically, they are paired with a second bearing to balance the load and enhance stability. Featuring an upper and lower shoulder, our single-row angular contact ball bearings are non-separable, ensuring a robust and reliable performance.

For more information or to discuss how our bearings can meet your specific needs, please contact us today!

Contact

Features Of Single Row Angular Contact Ball Bearing

Less axial space
Can be used for applications where two single row angular contact ball bearings arranged back-to-back take up too much axial space.
Accommodates radial as well as axial loads in either direction
Accommodates tilting moments
Stiff bearing arrangement

Specification of Single Row Angular Contact Ball Bearing

Dimensions				Basic load rating
Designations(Basic design bearing)	d	D	B	C	C0
7200 BEP	10	30	9	6.8094	3.2495
7201 BEP	12	32	10	7.3817	3.686
7301 BEP	12	37	12	10.282	4.85
7302 BEP	15	42	13	12.61	6.499
7303 BEP	17	47	14	15.423	8.051
7205 BEY	25	52	15	15.132	9.894
7305 BEY	25	62	17	25.22	15.132
7207 BEP	35	72	17	28.227	18.43
7307 BEP	35	80	21	37.83	23.765
7210 BEP	50	90	20	36.569	27.645
7312 BEP	60	130	31	92.732	67.415
7213 BEY	65	120	23	64.311	52.38
7313 BEP	65	140	33	104.76	77.6
7214 BEP	70	125	24	69.355	58.2
7314 BEP	70	150	35	115.43	87.3
7217 BEP	85	150	28	92.732	80.51
7218 BEP	90	160	30	104.76	93.605
7219 BEP	95	170	32	120.28	104.76
7220 BEP	100	180	34	130.95	118.34
7320 BEP	100	215	47	196.91	184.3
7222 BEP	110	200	38	158.11	148.41
7322 BEY	110	240	50	218.25	217.28
7224 BM	120	215	40	160.05	158.11
7226 BM	130	230	40	180.42	187.21
7326 BM	130	280	58	267.72	295.85
7228 BM	140	250	42	193.03	205.64
*7202 BECBP	15	35	11	8.536	4.5105
*7203 BECBM	17	40	12	10.67	5.6745
*7203 BECBP	17	40	12	10.67	5.6745
*7204 BECBM	20	47	14	13.871	7.9055
*7204 BECBP	20	47	14	13.871	7.9055
7204 BECBY	20	47	14	13.58	8.051
*7204 BECBPH	20	47	14	13.871	7.9055
*7304 BECBPH	20	52	15	18.43	9.7
*7304 BECBM	20	52	15	18.43	9.7
*7304 BECBP	20	52	15	18.43	9.7
7304 BECBY	20	52	15	18.43	10.088
*7205 BECBPH	25	52	15	15.132	9.7
*7205 BECBM	25	52	15	15.132	9.7
*7205 BECBP	25	52	15	15.132	9.7
*7305 BECBP	25	62	17	25.705	14.841
*7305 BECBM	25	62	17	25.705	14.841
*7206 BECBM	30	62	16	23.28	15.132
*7206 BECBP	30	62	16	23.28	15.132
7206 BECBY	30	62	16	23.086	15.132
*7206 BECBPH	30	62	16	23.086	15.132
*7306 BECBM	30	72	19	34.435	20.564
*7306 BECBP	30	72	19	34.435	20.564
7306 BECBY	30	72	19	34.435	20.564
*7306 BEGAPH	30	72	19	34.435	20.564
*7207 BECBPH	35	72	17	30.07	20.176
*7207 BECBM	35	72	17	30.07	20.176
*7207 BECBP	35	72	17	30.07	20.176
*7307 BECBM	35	80	21	40.255	25.705
*7307 BECBP	35	80	21	40.255	25.705
*7307 BEGAPH	35	80	21	40.255	25.705
*7208 BECBPH	40	80	18	35.405	25.22
*7208 BECBM	40	80	18	35.405	25.22
*7208 BECBP	40	80	18	35.405	25.22
7208 BECBY	40	80	18	35.308	25.22
*7308 BECBM	40	90	23	48.5	31.525
*7308 BECBP	40	90	23	48.5	31.525
7308 BECBY	40	90	23	47.918	32.495
*7308 BEGAPH	40	90	23	48.5	31.525
*7209 BECBM	45	85	19	36.86	27.645
*7209 BECBP	45	85	19	36.86	27.645
7209 BECBY	45	85	19	36.569	27.16
*7209 BEGAPH	45	85	19	36.86	27.645
*7309 BECBM	45	100	25	59.17	39.285
*7309 BECBP	45	100	25	59.17	39.285
7309 BECBY	45	100	25	58.685	40.255
*7309 BEGAPH	45	100	25	59.17	39.285
*7210 BECBPH	50	90	20	38.8	30.07
*7210 BECBM	50	90	20	38.8	30.07
*7210 BECBP	50	90	20	38.8	30.07
*7310 BECBM	50	110	27	72.75	49.47
*7310 BECBP	50	110	27	72.75	49.47
7310 BECBY	50	110	27	71.877	49.47
*7310 BEGAPH	50	110	27	72.75	49.47
*7211 BECBPH	55	100	21	47.53	38.8
*7211 BECBM	55	100	21	47.53	38.8
*7211 BECBP	55	100	21	47.53	38.8
7211 BECBY	55	100	21	47.336	36.86
*7311 BECBM	55	120	29	82.45	58.2
*7311 BECBP	55	120	29	82.45	58.2
7311 BECBY	55	120	29	82.644	58.2
*7311 BECBPH	55	120	29	82.45	58.2
*7212 BECBPH	60	110	22	59.17	48.5
*7212 BECBM	60	110	22	59.17	48.5
*7212 BECBP	60	110	22	59.17	48.5
7212 BECBY	60	110	22	55.484	44.135
*7312 BECBM	60	130	31	100.88	74.205
*7312 BECBP	60	130	31	100.88	74.205
*7312 BECBPH	60	130	31	100.88	74.205
*7213 BECBM	65	120	23	67.415	55.29
*7213 BECBP	65	120	23	67.415	55.29
*7213 BEGAPH	65	120	23	67.415	55.29
*7313 BECBM	65	140	33	112.52	83.905
*7313 BECBP	65	140	33	112.52	83.905
*7313 BECBPH	65	140	33	112.52	83.905
*7214 BECBM	70	125	24	69.84	58.2
*7214 BECBP	70	125	24	72.75	62.08
*7214 BECBPH	70	125	24	72.75	62.08
*7314 BECBM	70	150	35	123.19	95.06
*7314 BECBP	70	150	35	123.19	95.06
*7314 BECBPH	70	150	35	123.19	95.06
*7314 BEGAPH	70	150	35	123.19	95.06
*7215 BECBPH	75	130	25	71.295	63.535
*7215 BECBM	75	130	25	71.295	63.535
*7215 BECBP	75	130	25	71.295	63.535
7215 BECBY	75	130	25	70.616	62.08
*7315 BECBM	75	160	37	128.04	100.88
*7315 BECBP	75	160	37	128.04	100.88
7315 BECBY	75	160	37	129.01	102.82
*7315 BEGAPH	75	160	37	128.04	100.88
*7216 BECBPH	80	140	26	82.45	72.75
*7216 BECBM	80	140	26	82.45	72.75
*7216 BECBPH	80	140	26	82.45	72.75
7216 BECBY	80	140	26	80.704	71.295
*7216 BEGAPH	80	140	26	82.45	72.75
*7316 BECBPH	80	170	39	138.71	114.46
*7316 BECBM	80	170	39	138.71	114.46
*7316 BECBP	80	170	39	138.71	114.46
7316 BECBY	80	170	39	138.71	114.46
*7217 BECBM	85	150	28	98.94	87.3
*7217 BECBP	85	150	28	98.94	87.3
*7317 BECBM	85	180	41	151.32	128.04
*7317 BECBP	85	180	41	151.32	128.04
7317 BECBY	85	180	41	148.41	128.04
*7317 BEGAPH	85	180	41	151.32	128.04
*7218 BECBM	90	160	30	112.52	100.88
*7218 BECBP	90	160	30	112.52	100.88
*7318 BEGAPH	90	190	43	161.02	141.62
*7318 BECBM	90	190	43	161.02	141.62
*7318 BECBP	90	190	43	161.02	141.62
7318 BECBY	90	190	43	160.05	141.62
7219 BECBM	95	170	32	120.28	104.76
*7219 BECBP	95	170	32	125.13	114.46
*7219 BEGAPH	95	170	32	125.13	114.46
*7319 BECBM	95	200	45	174.6	158.11
*7319 BECBP	95	200	45	174.6	158.11
7319 BECBY	95	200	45	184.3	170.72
*7220 BECBM	100	180	34	138.71	129.98
*7220 BECBP	100	180	34	138.71	129.98
*7320 BECBM	100	215	47	209.52	201.76
*7320 BECBP	100	215	47	209.52	201.76
*7221 BECBM	105	190	36	151.32	145.5
*7221 BECBP	105	190	36	151.32	145.5
*7321 BECBM	105	225	49	209.52	201.76
*7321 BECBP	105	225	49	209.52	201.76
*7222 BECBM	110	200	38	158.11	151.32
*7222 BECBP	110	200	38	164.9	161.02
*7322 BECBM	110	240	50	232.8	237.65
*7322 BECBP	110	240	50	218.25	217.28
7024 BGM	120	180	28	84.487	90.21
7324 BCBM	120	260	55	230.86	242.5
7028 BGM	140	210	33	110.58	125.13
7328 BCBM	140	300	62	292.94	334.65
7030 BGM	150	225	35	129.01	141.62
7230 BCBM	150	270	45	209.52	232.8
7330 BCBM	150	320	65	322.04	378.3
7232 BCBM	160	290	48	247.35	291
7034 BGM	170	260	42	166.84	197.88
7234 BCBM	170	310	52	272.57	334.65
7334 BCBM	170	360	72	378.3	475.3
7036 BGM	180	280	46	189.15	232.8
7236 BCBM	180	320	52	282.27	363.75
7336 BCBM	180	380	75	397.7	523.8
7038 BGM	190	290	46	193.03	247.35
7238 BCBM	190	340	55	297.79	392.85
7338 BCBM	190	400	78	428.74	582
7040 BGM	200	310	51	218.25	281.3
7240 BCBM	200	360	58	315.25	417.1
7340 BCBM	200	420	80	448.14	635.35
7044 BGM	220	340	56	247.35	344.35
7244 BCBM	220	400	65	378.3	543.2
7048 BGM	240	360	56	252.2	363.75
7248 BCBM	240	440	72	353.08	523.8
7052 BGM	260	400	65	322.04	494.7
7056 BGM	280	420	65	327.86	523.8
7260 BCBM	300	540	65	536.41	902.1
7264 BCBM	320	580	92	554.84	989.4
*7305 BECBPH	25	62	17	25.705	14.841
